The Marin Rift Zone 1 is your gateway to the Rifty family, made to push the limits of your riding but not your bank balance. It's built with super reliable X-Fusion suspension, an X-Fusion Manic dropper post, grippy Vee Crown Gem tires, plenty of Shimano parts and a hand-picked selection of our favorite Marin components.
Series 3 6061 Aluminum, 27.5 or 29" Wheels, 130mm Travel, MultiTrac Suspension Platform, 148x12mm Boost Thru-Axle, 73mm Threaded BB w/ ISCG05 Tabs
X-Fusion Slide (29) or Sweep(27.5) Boost RC, 140mm Travel, Compression and Rebound Adjustment, 44mm Offset
X-Fusion O2 Pro R, Custom Tune, 210x55mm, M8x25mm Hardware Top and Bottom
Marin Aluminum Double Wall, 29mm Inner, Pinned Joint, Disc Specific, Tubeless Compatible
Shimano HB-MT200B, 141 QR, Centerlock, Standard Freehub Body
Shimano HF-MT400B, 110x15mm, Centerlock
14g Black Stainless Steel
Vee Tire Snap WCE 2.35", Top 40 Compound, GXE Core, 90 TPI, Tubeless compatible
Shimano, SL-U6000-11R, 11-Speed
Marin Forged Alloy, Integrated Steel 32T Narrow Wide Chainring, Boost Spacing
External Sealed Cartridge Bearing
Shimano LG-500 11-Speed
Shimano CS-LG400-11, 11-Speed, 11-50T
Tektro HD-M280 Hydraulic Disc, 180mm Rotor
Tektro HD-M280 Hydraulic Disc, 180mm Rotor
Tektro HD-M280
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back
Marin 3D Forged Alloy, 35mm
Marin MTN, Closed End
FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
X-Fusion Manic, 1x Composite Remote, Size XS-S 150mm Travel, Size M-XL 170mm Travel, 30.9mm
Marin Speed Concept
| Geometry | XS | S | M | L | XL |
|---|---|---|---|---|---|
| A Stack | 569.1 | 600.7 | 605.2 | 637.3 | 641.8 |
| B Reach | 415 | 430 | 450 | 485 | 515 |
| C Headtube angle | 65.5° | 65.5° | 65.5° | 65.5° | 65.5° |
| D Headtube length | 115 | 120 | 125 | 125 | 130 |
| E Seattube length | 330 | 390 | 400 | 425 | 430 |
| F Seattube angle | 77° | 77° | 77° | 77° | 77° |
| G Toptube effective | 552.6 | 568.7 | 589.7 | 632.1 | 663.2 |
| H Bb height | 339 | 339 | 339 | 343 | 343 |
| I Bb drop | 20 | 20 | 20 | 35 | 35 |
| J Chainstay | 430 | 430 | 430 | 430 | 430 |
| K Wheelbase | 1147.8 | 1164.8 | 1186.9 | 1234.4 | 1266.3 |
| L Standover height | 661.7 | 677.8 | 687.8 | 701.7 | 700.5 |
| M Fork offset | 44 | 44 | 44 | 44 | 44 |
| N Seatpost diameter | 30.9 | 30.9 | 30.9 | 30.9 | 30.9 |
| O Handlebar width | 780 | 780 | 780 | 780 | 780 |
| P Stem length | 35 | 35 | 35 | 35 | 35 |
| Q Crank length | 170 | 170 | 170 | 170 | 170 |
Your Height 5'3" / 160cm
slide the scale to your height measurement
You ride a
XS / Dark Purple / 27.5"
RIFT ZONE 1
