Dirt jump DNA with all the speed and roll-over of 29"" wheels. The Marin San Quentin 2 29 is our mid-pack model that blends bang-for-your-buck value with kick-ass components.
We’ve packed in 29"" wheels, a TranzX dropper post, X-Fusion suspension fork, Tektro four piston brakes, Vee Tire rubber and plenty of awesome Marin kit to create a bike you’ll love to rip, but that won’t shred your budget. Dirt jump DNA with all the speed and roll-over of 29"" wheels.
Series 3 6061 Aluminum, Double Butted Frame, Internal Cable Routing, 12x148mm Thru-Axle, 73mm Threaded BB
Rock Shox FS35 Silver, 110x15mm Boost Spacing, 140mm Travel, Maxle Stealth
Marin Aluminum Double Wall, Disc Specific, 29mm Inner, Pinned Joint, 32H, Tubeless Compatible
Shimano HF-MT400B, 148x12, Disc, Standard Freehub Body
Shimano HF-MT400B, 110x15mm, Disc
14g Black Stainless Steel
Vee Tire Co, Flow Snap, 27.5x2.6", MPC Compound, Wire Bead
Shimano Deore, 11-Speed, SL-5100R
Marin Forged Alloy, Integrated Steel 32T Narrow Wide Chainring, Boost Spacing
External Sealed Cartridge Bearing
KMC X-11 Silver and Black
SunRace, 11-Speed, 11-51T, ED Black
Shimano BR-MT201 Hydraulic Disc Brake, 180mm Rotor
Shimano BR-MT201 Hydraulic Disc Brake, 180mm Rotor
Shimano BR-MT201 Hydraulic Disc
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back
Marin 3D Forged Alloy, 35mm
Marin Grizzly Lock On
FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
TranzX, YSP18, 1x Remote, Size S 120mm Travel, Size M 150mm Travel, Size L-XL 170mm Travel, 30.9mm
Marin Speed Concept
Nylon Platform
| Geometry | S | M | L | XL |
|---|---|---|---|---|
| A Stack | 618 | 622.5 | 645 | 650 |
| B Reach | 422 | 450 | 470 | 500 |
| C Headtube angle | 64° | 64° | 64° | 64° |
| D Headtube length | 110 | 115 | 125 | 130 |
| E Seattube length | 310 | 340 | 410 | 420 |
| F Seattube angle | 77° | 77° | 77° | 77° |
| G Toptube effective | 564.7 | 593.7 | 619 | 650 |
| H Bb height | 316 | 316 | 327 | 327 |
| I Bb drop | 50 | 50 | 50 | 50 |
| J Chainstay | 425 | 425 | 430 | 430 |
| K Wheelbase | 1173.4 | 1203.6 | 1236 | 1268 |
| L Standover height | 627.7 | 656.4 | 688 | 695 |
| M Fork offset | 37 | 37 | 44 | 44 |
| N Seatpost diameter | 30.9 | 30.9 | 30.9 | 30.9 |
| O Handlebar width | 780 | 780 | 780 | 780 |
| P Stem length | 35 | 35 | 35 | 35 |
| Q Crank length | 170 | 170 | 170 | 170 |
Your Height 5'3" / 160cm
slide the scale to your height measurement
You ride a
Blue Fade / S / 27.5"
San Quentin 2
Make your Marin pop with our exclusive customizable graphics!
