2025 Gestalt 2

Gestalt 2

£1,449.00

Tarmac and trail, rough roads and muddy commutes, bikepacking, touring and adventure. Daily trips and weekend escapes are all within the Gestalt’s wheelhouse, with no stopping when the asphalt turns to dirt.

Our lightweight Series 3 aluminum frame is built to be lightweight, comfortable and confidence-boosting, with room for up to 45mm tires and we’ve paired it up with wide-range gearing, fender eyelets and powerful disc brakes that’ll tame all conditions and all-weather.

Colour: GLOSS BLACK

Size

Details Specifications

Fork

Marin Full Carbon w/ Tapered Steerer, 12mm Thru-Axle, Flat-Mount Disc, Fender Eyelets

Frame

Series 3 Beyond Road, 6061 Aluminum, Tapered Head Tube, Relieved BB, Internal Cable Routing, Mudguard and Rack Mounts, Flat Mount Disc, 142x12mm Thru-Axle

Rim

Marin Aluminum Double Wall, 21mm Inner, 22mm Tall, Disc Specific, Tubeless Compatible

Hub Rear

Forged Aluminum Alloy, Disc, 32H

Hub Front

Forged Aluminum Alloy, Disc, 32H

Spokes

14g

Tires

Vee Tire Co., Zilent, 700x35

Shift Lever

Shimano GRX, RX400, 2x10-Speed

Crankset

Shimano GRX, FC-RX600, 46/30T

Bottom Bracket

Shimano

Chain

KMC X10

Cassette

Shimano, HG-5010, 11-36T

Brakes Front

Shimano BR-RX400 Hydraulic Disc, 160mm Rotor

Brakes Rear

Shimano BR-RX400 Hydraulic Disc, 160mm Rotor

Brake Levers

Shimano w/ Integrated Shifters

Handlebar

Marin Butted Alloy, Compact 12º Flared Drop

Stem

Marin 3D Forged Alloy

Grips

Marin Perforated Tape

Headset

FSA No 42ACB, 1 1/8" x 1 1/2”

Seatpost

Marin Alloy, 27.2mm

Saddle

Marin Beyond Road Concept

Details Geometry

Geometry	50	52	54	56	58	60
A Stack	552	568	582	601	620	641
B Reach	367	372	377	387	402	404
C Headtube angle	71°	71.5°	71.5°	71.5°	71.5°	71.5°
D Headtube length	120	135	150	170	190	210
E Seattube length	460	480	500	520	540	560
F Seattube angle	74.5°	74°	73.5°	73.5°	73.5°	73°
G Toptube effective	520	535	550	565	585	600
H Bb height	276	276	276	276	276	276
I Bb drop	78	78	78	78	78	78
J Chainstay	432	432	432	432	432	432
K Wheelbase	1008	1014	1024	1040	1060	1070
L Standover height	714	732	755	775	794	814
M Fork offset	50	50	50	50	50	50
N Seatpost diameter	27.2	27.2	27.2	27.2	27.2	27.2
O Handlebar width	420	420	440	440	460	460
P Stem length	70	70	90	90	110	110
Q Crank length	170	170	175	175	175	175
