Alpine Trail 2

$8,551.75

$8,551.75

$8,551.75

$8,551.75

Trustpilot

The new Marin Alpine Trail Series 4 aluminum MultiTrac 2 LT frames feature mixed 29”/27.5” wheels, 170mm front and 160mm rear travel, and the utmost in adjustability. Riders can alter the head tube angle and bottom bracket/chain stay length, as well as run 29” rear wheels if desired. “Bear Box” downtube storage includes a zippered nylon bag to house trail essentials, and a 34.9mm seatpost increases strength and is compatible with the latest dropper posts.

While the Alpine Trail 1 is the starting point in the three-model lineup, we didn’t make any concessions regarding the spec. High-performance Fox suspension keeps you in control at all times, while a Shimano Deore 12-speed drivetrain transmits your power to the wheel. TRP’s Slate Evo 4-piston brakes feature 203mm rotors, keeping speed in check in a powerful, fade-free manner.

color: ASH BLUE BLACK
Size
s
Customize my ride

Tech Documents

Expand Tech Documents Collapse Tech Documents
View tech documents here (opens in new tab)

Geek Out

Expand Geek Out Collapse Geek Out

The Alpine Trail 2 turns up the heat. RockShox's Zeb Select+ fork delivers 170mm of buttery-smooth travel up front, perfectly matched to the Vivid Air Select+ rear shock's custom-tuned damper – together they're fettled for our 160mm travel MultiTrac LT suspension platform.

The Horst-link design balances progression, support and suppleness. Whether you're railing berms, hunting for traction or just sending it to flat, the design's neutral predictability has your back.

SRAM's Eagle 70 Transmission has bombproof reliability and direct-mount simplicity – expect crisp shifts and minimal fuss. Maven Bronze four-piston brakes with 200mm rotors defy physics with epic stopping power. We’ve fitted a Maxxis Assegai MaxxGrip EXO+ tire up front and MaxxTerra DoubleDown Minion DHR II out back – traction and puncture protection are perfectly balanced for the longest rides. The X-Fusion Manic HC dropper post adjusts travel in 10mm increments – dial in your perfect fit.

It has the same Series 4 Aluminum frame as the range-topping XR – maximum enduro, zero compromises. It's built to go hard with optimized tube shapes, a redesigned rocker link and carefully engineered chainstays make it epically capable. Weather-sealed internal cable routing, SRAM's UDH, Boost axle spacing and ride-hushing chain slap protection are the premium touches your rides deserve. Integrated Bear Box downtube storage keeps trail essentials close without overloading your bag.

Mixed wheels – 29in up front, 27.5in out back – beautifully combine stability and agility, or run full 29in for the ultimate charger. Lock in your personal set-up with tunable geometry. Swap out the upper headset cup for ±0.75 degrees of adjustment – go slack for fast descents or steepen it up for tight tech. Chainstay flip chips adjust bottom bracket height and chainstay length. Your sweet spot is just a few adjustments away – the Alpine Trail 2 brings the fire.

Specifications Geometry Technology Services & Support
2026 Alpine Trail 2
2026 Alpine Trail 2
2026 Alpine Trail 2
2026 Alpine Trail 2
2026 Alpine Trail 2

Specifications

SPEC AND PRICE BEING SUBJECT TO CHANGE WITHOUT NOTIFICATION

Fork

Fox 36 Rhythm, 170mm Travel, 29", Grip Damper, 110x10 Kabolt, 44mm Offset

Frame

Series 4 6061 Aluminum, 29” Wheels, 160mm Travel MultiTrac LT Suspension Platform, Integrated Downtube Storage, Adjustable Headset & CS Length/BB Height, Full Internal Cable Routing, Chainstay Mounted Post Mount Disc Brake, 148x12mm Boost Thru- Axle, 73mm Threaded BB w/ ISCG05 Tabs

Front Suspension

RockShox Zeb Select +, 170mm Travel, 29", 110x15mm Maxle Stealth, 44mm Offset

Rear Suspension

RockShox Vivid Air Select +, 205x65, 30xM8 Lower Hardware, Custom Tune

Rim

New Marin, Double Wall Alloy, 29mm Inner, Sleeved Joint, Disc Specific, 32H, Tubeless Compatible

Hub Rear

DT Swiss 370 Classic, 148x12mm, 6-Bolt Disc, HG Driver, 32H

Hub Front

Novatech, 110x15mm, 6-Bolt Disc, 32h

Spokes

14g Black Stainless Steel

Tires

Front: Maxxis Assegai MAXX GRIP, 29x2.5" EXO+ Rear: Maxxis Minion DHR II, MAXXTERRA, 27.5x2.5" DoubleDown, Tubeless compatible

Derailleur Rear

SRAM Eagle 70

Shift Lever

SRAM Eagle 90, MMX Clamp

Crankset

SRAM Eagle 70, 32T, 55MM CL, 170MM Length

Bottom Bracket

SRAM DUB MTB 73

Chain

SRAM Eagle 70 T-Type

Cassette

SRAM XG 1270, T-Type, 10-52T

Brakes Front

SRAM Maven Bronze, 4-Piston Hydraulic Disc , HSC 200mm Rotor

Brakes Rear

SRAM Maven Bronze, 4-Piston Hydraulic Disc , HSC 200mm Rotor

Brake Levers

SRAM Maven Bronze, MMX Clamps

Handlebar

Marin Trail, 35mm Clamp, 7000 Alloy Bar, 800mm Length, 20mm Rise, 5 Degree Up, 8 Degree Back

Stem

New Marin CNC, 35mm Length, 35mm Bar Bore

Grips

Marin Grizzly Lock-On

Headset

FSA Custom Headset, Adjustable HTA Design

Seatpost

X-Fusion Manic HC, Alloy Lever, Travel Adjust 10mm increments, Size S=150, M=170mm Travel, Size L-XL 200mm Travel, 34.9mm

Saddle

Marin Speed Concept

Extras

Bolt-On 12mm Thru-Axle, 174mm Length, 1.0 Thread Pitch, 16.5mm, Tapered Head

Geometry

View All Geometry Configurations
Geometry S M L XL
A Stack 620
B Reach 430
C Headtube angle 63.5°
D Headtube length 100
E Seattube length 400
F Seattube angle 79°
G Toptube effective 556
H Bb height 352
I Bb drop 24 | 7
J Chainstay 435
K Wheelbase 1211
L Standover height 683
M Fork offset 44
N Seatpost diameter 34.9
O Handlebar width 780
P Stem length 35
Q Crank length 160

2026 Alpine Trail 2

2026 Alpine Trail 2

Shimano Deore 12 Speed Drivetrain

Trans X Dropper Post

Series 4 Aluminum MultiTrac 2 LT Adjustable Frame

Fox Performance 170mm Fork

Marin Alpine Trail chainstay flip chip detail.

Adjustable Geometry

With the integrated flip chips, adjustable headset and an aftermarket 29” rear wheel, Alpine Trail aluminum riders can select 12 unique configurations to run their bikes. These configurations allow the best fine-tuning of chassis to trail conditions available. Flip chips are easy to reconfigure trailside and easily done using a 6mm hex wrench, require no additional parts, and incorporate laser-etched graphics that indicate the position of the chips. The stock 27.5” rear wheel can be swapped out for a 29” rear wheel (not included) if desired, along with changing the position of the seatstay flip chips. Furthermore, the flip chips located at the seatstay pivots alter the bottom bracket height and chainstay length (low BB/long CS setting = 345/442mm, high BB/short CS setting = 352/435mm) so that riders can perfectly dial their bike in to match the terrain they are looking to conquer.
