San Quentin 24
![2021 Marin San Quentin 24 profile.](https://s3.us-east-1.amazonaws.com/craft-marinbikes/images/2020/bikes/hero/_bikeHero320Wide/2021_San_Quentin_24_Color.jpg)
See this bike in a different color:
- Price: $1,799.00*
- Suspension: RockShox Judy Silver TK
- Frame: Aluminium
-
Size Range:
One Size
Size Rider height range ONE SIZE 122.5cm to 140cm
Jump to…
Specifications
-
Frame
Series 2 6061 Aluminum, 24” Wheels, Disc Specific, 135mm Dropouts
-
Front Suspension
RockShox Judy Silver TK, 100mm Travel, Solo Air, 110x15mm Maxle Stealth
-
Rims
Marin, Double Wall Alloy, 27mm Internal
-
Hub, Rear
Forged Aluminum, 32H, Disc Specific
-
Hub, Front
Forged Aluminum, 32H, Disc Specific
-
Spoke, Nipples
14g Stainless Steel
-
Tires
Vee Tire Crown Gem, 24”x2.6”, Wire Bead
-
Derailleur, Rear
MicroSHIFT Advent 9-Speed
-
Derailleur, Front
-
-
Shift Lever
MicroSHIFT Advent 9-Speed
-
Crankset
Forged Alloy, Narrow Wide 30T, 152mm
-
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
-
Chain
KMC X9
-
Cassette
MicroSHIFT 9-Speed, 11-46T
-
Brake, Front
Shimano BR-MT201 Hydraulic, 160mm Rotor
-
Brake, Rear
Shimano BR-MT201 Hydraulic, 160mm Rotor
-
Brake Levers
Shimano Hydraulic
-
Handlebar
Marin Riser, 31.8 clamp, 30mm Rise, 590mm Width
-
Stem
Marin Alloy, 35mm
-
Grips
Marin MTB
-
Headset
FSA No. 57E
-
Seatpost
Marin Alloy, 30.9mm
-
Saddle
Marin Kids MTB
-
Pedals
Kids Specific Nylon Pedal
Specifications, pricing, and availability are subject to change without notice.
Geometry
![San Quentin 24 geometry diagram](https://s3.us-east-1.amazonaws.com/craft-marinbikes/images/2020/bikes/geometry/_bikeGeometry320Wide/21_MRN_GEO_ALL_HARDTAILS_1416px.jpg)
ONE SIZE | |
---|---|
Stack | 540.5 |
Reach | 345 |
Headtube Angle | 65° |
Headtube Length | 90 |
Seattube Angle | 75° |
Seattube Length | 321 |
Toptube Effective | 489.8 |
BB Height | 290 |
BB Drop | 30 |
Chainstay | 369.9 |
Wheelbase | 1029.4 |
Standover Height | 576.87 |
Fork Offset | 42 |
Seatpost Diameter | 30.9 |
Handlebar Width | 590 |
Stem Length | 35 |
Crank Length | 152 |
All lengths in millimeters
