The Marin Rift Zone 2 is the Rifty everyone wants to ride, with a hand-picked selection of our favorite components. We've chosen a buttery-smooth Marzocchi and RockShox suspension duo, grippy Vee Flow Snap WCE tires, plenty of super-reliable Shimano components and a whole load of our favorite Marin finer details to complete the package.
Series 3 6061 Aluminum Frame, 29” Wheels, 130mm Travel, MultiTrac Suspension Platform, 148x12mm Boost Thru-Axle, 73mm Threaded BB w/ ISCG05 Tabs
Marzocchi Bomber Z2 29", Rail Damper with Sweep Adjustment, 140mm Travel, Kabolt Bolt-On Axle, 44mm Offset
RockShox Deluxe Select RT, Debonair Air Sleeve, Rebound Adjustment, Custom Tune, 210x50mm, M8x25mm Hardware
Marin, Double Wall Alloy, 29mm Inner, Pinned Joint, Disc Specific, 32H, Tubeless Compatible
Shimano FH-TC500, 148x12mm, Disc, HG Freehub Body
Shimano HF-MT410B, 110x15mm, Centerlock
14g Black Stainless Steel
Vee Tire Snap WCE 2.35", Top 40 Compound, GXE Core, 90 TPI, Tubeless compatible
Shimano Deore, 12-Speed, SGS
Shimano Deore, 12-Speed, SL-M6100-R
FSA Comet, Modular 1x, 32T Direct Mount Chainring, MegaTooth Technology, Boost Spacing
External Sealed Cartridge Bearing
KMC X-12 Silver and Black
Sunrace, 12-Speed, 11-51T
Tektro HD-M535 Hydraulic Disc, 180mm Rotor
Tektro HD-M535 Hydraulic Disc, 180mm Rotor
Tektro HD-M535, 180mm Rotor
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back
Marin 3D Forged Alloy, 35mm
Marin Grizzly Lock On
FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
X-Fusion Manic, 1x Composite Remote, Size S 150mm Travel, Size M-XL 170mm Travel, 30.9mm
Marin Speed Concept
Bolt-On 12mm Thru-Axle, 174mm Length, 1.0 Thread Pitch, 16.5mm, Tapered Head
| Geometry | S | M | L | XL |
|---|---|---|---|---|
| A Stack | 600.7 | 605.2 | 637.3 | 641.8 |
| B Reach | 430 | 450 | 485 | 515 |
| C Headtube angle | 65.5° | 65.5° | 65.5° | 65.5° |
| D Headtube length | 120 | 125 | 125 | 130 |
| E Seattube length | 390 | 400 | 425 | 430 |
| F Seattube angle | 77° | 77° | 77° | 77° |
| G Toptube effective | 568.7 | 589.7 | 632.1 | 663.2 |
| H Bb height | 339 | 339 | 343 | 343 |
| I Bb drop | 20 | 20 | 35 | 35 |
| J Chainstay | 430 | 430 | 430 | 430 |
| K Wheelbase | 1164.8 | 1186.9 | 1234.4 | 1266.3 |
| L Standover height | 677.8 | 687.8 | 701.7 | 700.5 |
| M Fork offset | 44 | 44 | 44 | 44 |
| N Seatpost diameter | 30.9 | 30.9 | 30.9 | 30.9 |
| O Handlebar width | 780 | 780 | 780 | 780 |
| P Stem length | 35 | 35 | ||
| Q Crank length | 170 | 170 |
Your Height 5'3" / 160cm
slide the scale to your height measurement
You ride a
Grey/Blue / S / 27.5"
Rift Zone 2
